    your location : Home  > Products > Resistance > Surge protection type varistor >

    Electronic circuit overvoltage protection type varistors

    7D

    Features :

    ● small and compact, surge resistant, large power flow
    ● excellent sensitivity to transient surge
    ● low limiting voltage and reliable protection effect
    ● no freewheeling
    ● ROHS directive has been complied with, halogen free

    Email : wd@szweidy.com

    Consult now PDF download

    Advantage

    Chips that comply with national standards are used to mitigate safety risks and avoid explosions
    A large silver-plated surface area, containing up to over 75% Ag, with strong impact resistance and free of perforations
    Featuring properties such as high insulation, superb thermal-performance, and exceptional flame-retardancy, the flame-retardant epoxy resin encapsulation used is compliant with the UL94V-0 standard
    Free of exposed copper, scratches, and oxidation, the tinned copper-clad steel CP leads to conform to strict process-level implementation standards

    Related

    7D

    20D

    10D

    14D
